/ Product catalogue / Commercial and industrial ventilation / Inline fans / For round duct / Iso-V EC / Iso-V EC 315
| Unit of measurement | Iso-V EC 315 | |
| Connected air duct size | mm | 315 |
| Phases | - | 1 |
| Minimum supply voltage | V | 200 |
| Maximum supply voltage | V | 240 |
| Power supply frequency | Hz | 50/60 |
| Rated power | W | 150 |
| Unit current | A | 1.23 |
| Maximum airflow | m³/h | 2370 |
| Rotation speed at 50hz | - | 1600 |
| Sound pressure level LpA at 3 m | dB(A) | 35 |
| Weight | kg | 25.7 |
| Transported air temperature (max) | °С | 80 |
| Transported air temperature (min) | °С | -40 |
| Ingress protection rating | - | IPX4 |
| Impeller material | - | Plastic |
| Trademark | Blauberg |
| Model | Iso-V EC 315 |
| Type of ventilation unit | Unidirectional |
| Type of drive installed | Integrated VSD |
| Type of heat recovery system | None |
| Nominal external pressure (Pa) | 223 |
| Maximum external leakage rates (%) | 2.7 |
| Static efficiency (%) | 70.2 |
| Declared typology | NRVU UVU |
| Effective electric power input (kW) | 0.15 |
| Sound power level (dB(A)) | 55 |
| A |
|---|
| 500 |
| Name | Photo | Description |
|---|---|---|
| Blauberg CDT E/0-10 |
|
Speed control for EC motors |
